TMREC-4KS HDMI Media Recorder with 4K60P Input Support
TMREC-4KS
New product
This is an HDMI media recorder with a built-in LCD monitor and battery, capable of 4K60Hz input/output and recording at 4K30P.
It also supports AV input, allowing compatibility with composite input through the included AV cable. You can utilize it to digitally preserve and store the visuals from analog devices such as VHS.
More info
| Model No. | TMREC-4KS | JAN | 4533239033809 |
| Input | 3840x2160 (60P), 3840x2160 (30P), 720x576 (50p) 1920x1080 (60p), 1920x1080 (50p) 1920x1080 (30p), 1920x1080 (25p) 1920x1080 (24p), 1280x720 (60p) 1280x720 (50p), 720x480 (60p) |
| HDMI Output Resolution | 1920x1080 (60p) |
| Recording Resolution | HDMI input recording resolution： 3840×2160(60p)、3840×2160(30p)、1920×1080(60p)、 1280×720(60p) Composite Input Resolution Auto-Detect＝720 × 480（3：2）Or 640 × 480（ 4 : 3 ) 640 × 480 （4 : 3）Fixed ※Recording bitrate for AV input is 5MBPS |
| Recording Format | MP4 (H.264) |
| Composite Input | NTSC、PAL |
| Input Terminal | HDMI、AV、Earphone (4-pole CTIA earphone microphone)、 microUSB |
| Output Terminal | HDMI、microSD、USB、Earphone |
| Supported File System | FAT32、NTFS、exFAT |
| 1 file recording capacity for each file system | Up to 32GB (NTFS / exFAT)、4GB(FAT32) |
| Recording Bitrate | 30 / 25 / 20 / 15 / 10 / 5 (Mbps) |
| Compatible Storage | 512GB(USB Flash Drive / microSD)、 HDD 2TB（2.5 Inches Recommended） |
| Weight | 155g |
| Product Size | W142 × D68 × H22 mm |
| Built-in Speaker Out | １W |
| Power Supply | DC 5V, 2A |
